How to make ESD safe work surface? Polstar ESD Control Table Mat is on the basic line of this question. Polstar ESD Control Table Mat has two co-extruded layer constructions, and these two layers are strongly stuck together and become the homogenous body.

Thanks to its stable quality and stable surface resistance, our ESD Control Table Mat is commonly used as the top material of assembly lines, worktable, etc. in electronics and semiconductor factories and many other static controlled areas.

Standard
Item Code M11M-000
Thickness 1.5 mm, 1.8 mm, 2 mm, 3 mm
Width 60, 70, 80, 90, 100, 120 cm
Length 10 m / roll
Surface Resistance Top 10e8 ~ 10e9 ohm
Bottom 10e3 ~ 10e6 ohm
Color Green/Black, Dark Green/Black, Blue/Black,
Sky Blue/Black, Grey/Black, Brown/Black, Beige/ Black
Layer

  • Static Dissipative Rubber
    (30~20% in thick)
  • Conductive Rubber
    (70~80% in thick)



Low S/R
Item Code M11M-000
Thickness 2 mm, 3 mm
Width 60, 70, 80, 90, 100, 120 cm
Length 10 m / roll
Surface Resistance Top 10e6 ~ 10e8 ohm
Bottom 10e3 ~ 10e6 ohm
Color Green/Black, Blue/Black, Grey/Black
* Other colors are also available on request
Layer

  • Static Dissipative Rubber
    (30~20% in thick)
  • Conductive Rubber
    (70~80% in thick)
