Conductive Corrugated Sheet & Box
Free

Conductive Corrugated Sheet & Box

General Information

  • Standard Size : 1200 x 2400 mm
  • Available Thickness : 3, 4, 5, 8, 9T
  • Color : Black
  • Material: Conductive PP

Features

  • Light weight, good property against water, chemicals and oils.
  • Semi-permanent conductive property, high durability
  • Economical cost, low minimum quantity
  • Easy to fabricate, custom-made

Applications

  • Normally, 3, 4, 5 mm thickness are used a lot. The applications is as below:
  • 3 mm: packing material to reduce impact, material of stationery, Material of humidity prevention
  • 4mm: Panel for car partition, crown plate of bathroom, outer packing material
  • 5mm: Packing material for exportation, container box, luggage carrier etc



Product Inquiry +

Reviews

There are no reviews yet.

Be the first to review “Conductive Corrugated Sheet & Box”

Need Help? Contact Us Leave Feedback

Category: .

Share
Items Units Spec Test methods
Specific gravity 1.050 ~ 1.150 ASTM D 792
Tensile strength kg/㎠ MIN. 250 ASTM D 638
Surface resistivity EΩ/sq E2 ~ E3 ASTM D 257
Melt index g/10min 0.80 ~ 1.20 ASTM D 1238
Flexural strength ㎏f/㎠ MIN. 350 ASTM D 790
Flexural modulus ㎏f/㎠ MIN. 18,000 ASTM D 790
Izod impact strength ㎏㎝/㎝ MIN. 20 ASTM D 256
HDT @66psi MIN. 105 ASTM D 648
Appearance BLACK PELLETS
