KORENG

Antistatic Utility Tape (Halogen Free + Standard)

Metalized PET film with antistatic acrylic adhesive

Constructions



  • Metalized PET (25㎛)
  • Antistatic treatment
  • Antistatic acrylic adhesive (25㎛)
Product Enquiry
Categories: ,

Description

Item Code M38T-000
Model NAT-801
Surface Resistance 10e7 ~ 10e9, Back – 10e11 ~ 10e12 ohm
Thickness 50㎛
Size 1/2″, 1″, 3/4″, 2″×50m/roll, 1200mm×50m (Jumbo roll)
Packing 25mm×50m/100rolls, 50mm×50m/50rolls



ESD Packing Tapes

ESD Packing Tapes were developed to protect static sensitive products from static electricity generated by triboelectricity when they are unrolled or removed from various objects our ESD packing tapes relatively generate very low static voltage while normal tapes generate about over 1KV to 9.5KV to 14KV under the same conditions.

Applications
  • Bundle of DIP IC Tube
  • Seal Static Shielding Bag
  • Pack Conductive IC Tray
  • Pack Wafer Carrier
  • Attach a Note in Cleanroom
  • EMI Shielding
  • Holes or Connector Pins
  • Covers for External Plugs
